Mounting hole spacing

124,5x124,5 mm

Connector & pin-configuration

4-pin PWM

Cable length

20cm + 30cm NA-EC1 extension cable

Bearing

SSO2

Blade geometry

A-Series with Flow Acceleration Channels

Frame technology

AAO (Advanced Acoustic Optimisation)

Rotational speed (+/- 10%)

1500 RPM

Min. rotational speed @ 20% PWM (+/-20%)

300 RPM

Airflow

140,2 m ³/h

Acoustical noise

24,6 dB(A)

Static pressure

2,08 mm H ‚‚O

Input power (typical)

0,99 W

Input power (max.)

1,3 W

Input current (typical)

0,198 A

Max. input current

0,26 A

Operating voltage

5 V

MTTF

> 150.000 h

Scope of delivery

30cm extension cable

NA-AV1 anti-vibration mounts

USB power adaptor cable

OmniJoin adaptor set

Fan screws
